80mm Handle  140 Bags Min Roller Sos Shopping Paper Bag Manufacturing Machines

80mm Handle 140 Bags Min Roller Sos Shopping Paper Bag Manufacturing Machines

Product Details:

Place of Origin: CHINA
Brand Name: SUNHOPE
Certification: CE
Model Number: SBH330B-508TH

Payment & Shipping Terms:

Minimum Order Quantity: 1PC
Packaging Details: Wooden Case
Delivery Time: 3-10 months
Payment Terms: T/T, L/C
Get Best Price Contact Now

Detail Information

Model No.: SBH330B-508TH Bag Type: Shopping Bag
Glue System: Nordson Cold Glue System Motion Controller: Mitsubishi Touch Screen Display
Main Bearing: NSK Japan Tension Control System: Mitsubishi Tension Control System
Web Guiding Control System: Bst Web Guiding Control System Cut Off Length: 280-530mm
Flat Handle Paper Thickness: 70-80mm Max Speed: 140 Bags/min
High Light:

140bags Paper Bag Manufacturing Machines

,

80mm Paper Bag Manufacturing Machines

,

80mm Paper Bag Manufacturers Machine

Product Description

80mm Handle 140 Bags Min Roller Sos Shopping Paper Bag Manufacturing Machines

SBH330B-508TH Automatic High Speed Roller Square Bottom Sos Shopping Kraft Paper Bag Making Machine



SBH330B-518TH model paper bag making machine is designed to manufacture square bottom paper bags from paper roll in blank or printed. Side gluing, tube forming, cutting, bottom impressing, bottom gluing, bottom forming can be completed within one time by this machine. The flat handle inside the bag greatly saves the packing case size and the cost. It is ideal equipment for making small paper bag for foodstuff bag, shopping bag and so on.





Structure Features:



1.Equipped with Japan Mitsubishi servo system and SICK photocell for correction, tracking the printed material accurately, minimize the adjustment and preset time, increase the production efficiency.


2.Equipped with Mitsubishi electric control system, Mitsubishi motion controller (CPU), through the integration of and optical fiber to realize high speed and high precision, motion control,


3.Production flow test. The touch screen display, the operation function is clear and has good human-machine interface


4.Fault the automatic alarm, equipped with wall paper detector, avoid because plugging paper and damaged machine.


5.Automatic grease lubrication supply system, blocking alarm.


6.Equipped American Nordson cold spray adhesive system for bag side seal, ensure high-speed state side sealing, and adjust glue volume with mechanical speed automatic , save glue!



Technical Parameters For  Automatic High Speed Roller Square Bottom Sos Shopping Kraft Paper Bag Making Machine

80mm Handle  140 Bags Min Roller Sos Shopping Paper Bag Manufacturing Machines 0

Model SBH330B-508TH
Paper Roll With(mm) 530-1050
paper Roll Dia.(mm) ≤1500
Paper Roll Core Dia.(mm) φ76
Paper Thickness(gsm) 50-160
Tube Cut Off Length(mm) 280-530
Bag Face Width(mm) 200-330
Bag Bottom Size(mm) 70-150
Flat Handle Height(A) (mm) 75
Handle Patching Width(B) (mm) 52
Handle Patching Length(C) (mm) 155
Flat Handle Pitch(D) (mm) 100
Flat Handle Width(E) (mm) 12
Flat Handle Paper Roll Width(mm) 95
Flat Handle Paper Thickness(gsm) 70-80
Flat Handle Paper Roll Dia.(mm) 1200
Handle Paper Patch Roll Diameter(mm) 1200
Handle Paper Pacth Roll Width(mm) 155
Handle Paper Patch Thickness(gsm) 80-110
Max.Speed(bags/min) 140
Total Power(KW) 23.9
Machine Weight(kg) 23000
Machine Size((L×W×H)m) 14.85×4.2×2.8

80mm Handle  140 Bags Min Roller Sos Shopping Paper Bag Manufacturing Machines 1     80mm Handle  140 Bags Min Roller Sos Shopping Paper Bag Manufacturing Machines 2



                   Flat Handle Unit                                                              Machnical Drive
